Transfer Method: Drawer Type
PCB Tray: High temperature resistant transparent tray
Accessible height: 40±5mm
Working area:360×300mm
Control Method
Control Mode: PID+Computer
Communication Mode: RS485
Heat Method
Temperature zone: Single zone 16 stage Temp control
Number of temperature control stage: 1~16 stage,which can be set according to actual.
Temp Control Method:Microcomputer automatic temp control, SSR
contactless output
Temp control range: Short time high temperature Max350 ℃, high
temperature resistance, suitable for high temperature soldering
Heater: Ceramic radiant plate
Temp curve: 1~4 Temp curve can be set,each curve is controlled by 16 stage.
Control accuracy: ±5℃
Furnace liner material:8K mirror stainless steel
Cooling System
Cooling Method: Turbocharger suction cooling
Temp Drop slope: 1~3℃/sec
Cooling Pipe: Independent exhaust air duct, with external
exhaust interface as standard
More Details:
Start Power: 2.6kw
Working Power: 1.0kw
Weight: 45kg
Voltage: Single AC,220V,50Hz
Size: 817X504X322mm
