Full Automatic Type SMD SMT Pick And Place Machine LED SMT Assembly Machine HW-DSQ800-120F For SMT Production Line
Beijing HuaweiGuochuang Electronic Technology Co. Ltd. is a Chinese high-tech enterprise with inte-grated research and development
(R&D), producti-on and sales operations. The pick and place machi-ne, SMT's main equipment, is our key research and development
equipment.
Our vision is to become an enterprise which ma-kes cost-effective domestic pick and place machine of our own and we intend to
break the current situ-ation of international monopoly.
We have maintained the philosophy of being pa-triotic, pragmatic, innovative as well as serving the society. The products of pick
and place machine on sale are not only appreciated by small and medium-sized enterprises at home, but also very well receiv-ed by
consumers abroad.
|
|
|
|
|
|
Control Computer
|
industrial control computer with intel high-performance processor
|
|
Adjusting Method of Tracks
|
electric
|
|
|
4.5mm
|
|
Maximum Step Length of Z Axis
|
50mm
|
|
Range of Angle for Components
|
士180°
|
|
Motor
|
Panasonic AC Servo Motor MINAS A6 series
|
|
Driver
|
Panasonic high-speed DSP driver
|
|
Air Supply Requirements
|
oil water filter,> 60L dust filter and air pressure stabilizer etc
|
|
Vacuum Supply of Nozzle
|
Japanese CKD vacuum generator integrating the high-speed vacuum burst function
|
Range of Air Supply Pressure
|
0.5-0.6mp
|
|
OS
|
independent research and development SMT intelligent OS based on Windows
|
|
Vision Display
|
17-inch industrial control display
|
|
|
German lgus durable flexible cable(10 million times)
|
|
Power Supply
|
220V 50/60Hz
|
|
|
1500W
|
|
Machine Dimensions
|
1740*1360*1440mm
|
|
Weight
|
1100Kg
|
