Hot Sales HWGC used smt machine Pick and Place Machine Automatic Electronics Production Machinery
120pcs material stations -- can meet the mounting requirements of various materials and various specifications and packages of the product.
120pcs 8mm material stations support NXT electric feeder, 12mm, 16mm, 24mm, 32mm and 44mm NXT electric feeder,,vibration feeder and IC trays.
NXT electric platform specification: 8mm-44mm NXT electric feeder, electric feeder stable feeding, high precision, long service life.
|
|
|
Number of Placement Heads
|
8(high-accuracy)
|
|
Number of iC Trays
|
96
|
|
Number of Feeders
|
120(subject to 8mm feeder)
|
|
Positioning Accuracy
|
0.01mm
|
|
Repeated Mounting Accuracy
|
0.02mm
|
|
Range of Mounting Speed
|
20000-26000Pcs/h
|
|
Applicable Components
|
resistor.capacitor.chip.lamp bead etc.
|
Introduction
The machine H4 with the ball screw and servo motor which is more stable and accurate than normal step motor, software designed and developed by our self. It is available in English. And we will keep updating it. Customers can get updated software regularly. Machine is of high quality,with at least one-year warranty, lifetime maintenance
Feature
SMT pick and place machine with 50 feeders +4 heads adopts Panasonic servo motor to ensure it is stable and accuracy 2. SMT pick and place machine uses imported Straight guide rail +screw Guide can get faster speed and more stable 3. Four mounting heads work together, under 6 cameras inspection,come with 50 feeder positions will make machine working more
Part List
Pick and place machine:1Set 2.IC fixed support:4Sets (four M5*8, four M5*16) 3.JUKI nozzle:12Pcs (502*2,503*3,504*4,505*2,506*1) 4.Calibration suction nozzle:4PCS 5.Power wire:1PC 6.Fixed foot:4PCS (Diameter 20mm) 7.The keyboard and mouse:1Set 8.Nozzle calibration ink-pad:1Box 9.lubricant:1PC 10.Chassis key:1PC 11.PC:1Set 12.17-inch liquid crystal display:1Set
