Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots

Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots

Products - SMT Pick And Place Machine
  • High Light

    Pneumatic SMT Pick And Place Machine

    ,

    8mm SMT Pick And Place Machine

    ,

    8 Heads pneumatic pick and place robot

  • Number Of Placement Heads
    8
  • Number Of IC Trays
    96
  • Number Of Feeders
    120 PCS 8mm NXT Feeder
  • Control System
    HWGC Control System
  • Weight
    1100Kg
  • Machine Dimensions
    1740*1360*1440mm
  • Place of Origin
    China
  • Brand Name
    HWGC
  • Certification
    CE
  • Model Number
    HW-DSQ800-120F
  • Minimum Order Quantity
    1
  • Price
    USD+25000+Pieces
  • Packaging Details
    Export wooden package
  • Delivery Time
    5-8work days
  • Payment Terms
    T/T
  • Supply Ability
    100+Pieces+Month

Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots

  • Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots
Get Price Contact Now

SMT Online 8 Heads Pick And Place Machine With 120 Feeder slots Pick And Place Robot



porduct description

The HW-DSQ800-120F is our most popular model with Vision. The HW-DSQ800-120F offers technologically advanced features with 120 single feeder positions  where quick setup, easy of operation and high reliability are paramount.



System Features



* The highest quality with the most advanced equipment at a cost-effective solution

*Placement rates up to 26000 cph

*Accurately places a wide range of components including 0201, 0402, LED, BGA, QFN...




Placement rates 26000CPH
Accuracy ± .001” (0.02mm)
Voltage 220AC
Weight 1100kg
Warranty 1 year
Suppport Video Support
UI The best GUI (graphical user interface) in its class using Windows®-based software allows programming in minutes
Max no. of Feeders (8mm tape) Max no. of Feeders (8mm tape)
Max Board Size 260mmX400mm
Smallest Component Capability 0201
Vision System HWGC Vision
Vibratory Feeders NXT Feeder, tube, stick (frequency & amplitude control)


The HW vision System assist allows accurate placement of 0201, BGA, QFN, QFP,LED and a wide range of virtually all SMT components.

Our Advantages
1.120pcs material stations -- can meet the mounting requirements of various materials and various specifications and packages of the product.

1) 120pcs 8mm material stations support NXT electric feeder, 12mm, 16mm, 24mm, 32mm and 44mm NXT electric feeder,,vibration feeder and IC trays.
2)NXT electric platform specification: 8mm-44mm NXT electric feeder, electric feeder stable feeding, high precision, long service life.

2.8 groups of independent mounting heads - 8 groups of mounting heads are distributed with different nozzles, which are suitable for the mounting requirements of products with more specifications.

1) 8 groups of mounting heads can realize the double arms and four heads pick simultaneously,pick up the material at same time, The picking efficiency is improved greatly.
2)The mounting head can rise and fall independently, rotate from 0 to 360 degrees, and mount up to 20 mm components.
3)The z-axis can rise and fall independently according to the thickness of the components,For the resistance and capacitance components, the mounting head can realize the fly visual identification, High components can be mounted at reduced speed.
4)It can meet the requirements of different sizes of components, different specifications and different packages, achieve diversity, one-time placement.

Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots 0Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots 1Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots 2

porduct description

The HW-DSQ800-120F is our most popular model with Vision. The HW-DSQ800-120F offers technologically advanced features with 260mm x 400mm work area, 120 single feeder positions where quick setup, easy of operation and high reliability are paramount.

Vision System

The HW-series vision pick and place systems is easy to programming for all operators, Intelligent and fast to operation



Feeders

NXT Electricial feeder were adopted, sizes include 8mm, 12mm, 16mm, 24 mm, 32mm and 44mm.

Tags:

OEM SMT Pick And Place Machine

8 Heads SMT Pick And Place Machine

QFP BGA Pick And Place Machine
