120pcs material stations -- can meet the mounting requirements of various materials and various specifications and packages of the product.
120pcs 8mm material stations support NXT electric feeder, 12mm, 16mm, 24mm, 32mm and 44mm NXT electric feeder,,vibration feeder and IC trays.
NXT electric platform specification: 8mm-44mm NXT electric feeder, electric feeder stable feeding, high precision, long service life.
8 groups of independent mounting heads - 8 groups of mounting heads are distributed with different nozzles, which are suitable for the mounting requirements of products with more specifications.
8 groups of mounting heads can realize the double arms and four heads pick simultaneously,pick up the material at same time, The picking efficiency is improved greatly.
The mounting head can rise and fall independently, rotate from 0 to 360 degrees, and mount up to 20 mm components.
It can meet the requirements of different sizes of components, different specifications and different packages, achieve diversity, one-time placement.
The comprehensive efficiency is 20000pcs/h, and the maximum efficiency is 26000pcs/h.
Mounting speed of various components(resistance,capacitance,chip)20000 pcs/h.
Only capacitance or resistance or LED lamp mounting speed is 26000pcs/h.
PCB with thickness less than 3mm, 340*560mm.
Support PCB with thickness of 1 mm-3 mm.
Support minimum width of 50 mm, maximum width of 560 mm PCB, length of 340 mm PCB.
