120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment

Products - SMT Chip Mounter
  • High Light

    120 Feeders Smd Led Making Machine

    ,

    OEM Smd Led Making Machine

    ,

    HWGC PCB Production Line Equipment

  • MAX Circuit Board Area
    340*560mm
  • Vision On
    20000pcs/h
  • Number Of Head
    8
  • Software
    English
  • Number Of Camera
    11
  • Vision Display
    17-inch Industrial Control Display
  • Air Source Quality Requirements
    Oil Water Filter;≥60L,dust Filter And Air Pressure Stabilizer Etc
  • Product Weight
    500KG
  • Place of Origin
    CHINA
  • Brand Name
    HWGC
  • Model Number
    HW-DSQ800-120F
  • Minimum Order Quantity
    1
  • Price
    24500-24800$
  • Delivery Time
    8 work day
  • Payment Terms
    T/T

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment

  • 120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment
Get Price Contact Now

Professional imported 5MP industrial calibration HD camera used for mounting chips and its supporting 5MP distortion-free induatrial vision HD lens.
Eight 1MP industrial fast recognition cameras which can incr-ease efficiency significantly by simultaneous recognition of eig-ht placement heads.

Introduction

Based on 6 mounting heads +8 cameras+64 feeder positions+ Panasonic
Servo motor+guide screw, the positioning is highly developed(PRECISION:0.01MM)
SMT PNP Machine can pick 0201, 0402, 0603, 0805, 1206, diode, triode, SOT, and QFP, BGA, etc. With lead pitch ≥0.3mm (pin center distance 0.5mm) within 40 * 40mm.

Part List


Item
Description
Quantity
Remarks
1
Pick and place machine
1 Set
110/220V
2
IC fixed support
4 Sets
Four M5*8,four M5*6
3
JUKl nozzle
16 Pieces
502*4,503*4,504*4,505*3,506*1
4
Calibration suction nozzle
4 Pieces

5
Power wire
1 Piece

6
Fixed foot
4 Pieces
Diameter 20mm
7
The keyboard and mouse
1 Set

8
Nozzle calibration inkpad
1 Box

9
lubricant
1 Piece

10
Chassis key
1 Piece

11
PC
1 Set

12
17 inch liquid crystal display
1 Set

Products Description
Specification
Number of Placement Heads
8(high-accuracy)
Number of iC Trays
96
Number of Feeders
120(subject to 8mm feeder)
Positioning Accuracy
0.01mm
Repeated Mounting Accuracy
0.02mm
Range of Mounting Speed
20000-26000Pcs/h
Applicable Components
resistor.capacitor.chip.lamp bead etc.
Supported Maximum Area of PCB
340*560mm
Feeders
NXT electric feeder,vibrating feeder, IC tray etc
Recognition Devices
mark camera x2,fast recognition camera x8. high-precision camera x1
Maximum Height of Applicable Components
≤20mm
Recognition Methods
simultaneous recognition and picking with eight heads
PCB Convey Mode
three-stage entry automatic connection from left to right, automatic PCB positioning
Mark Positioning
manual/automatic
Programming Method
automatic programming after manually importing files of PCB coordinates
Control System
HuaweiGuochuang 2021 control system
Maximum Step Length of XY Axis
423mm*734mm(left)423mm*734mm(right)
Tracks of XY Axis
four linear motion quide + four ground ball screw
Motion Mode of XY Axis
intelligent linkage of acceleration and deceleration of curve and line, integrated linear interpolation algorithm
Control Computer
industrial control computer with intel high-performance processor
Adjusting Method of Tracks
electric
Range of Nozzle Buffer
4.5mm
Maximum Step Length of Z Axis
50mm
Range of Angle for Components
士180°
Motor
Panasonic AC Servo Motor MINAS A6 series
Driver
Panasonic high-speed DSP driver
Air Supply Requirements
oil water filter,> 60L dust filter and air pressure stabilizer etc
Vacuum Supply of Nozzle
Japanese CKD vacuum generator integrating the high-speed vacuum burst function
Range of Air Supply Pressure
0.5-0.6mp
OS
independent research and development SMT intelligent OS based on Windows
Vision Display
17-inch industrial control display
Cable
German lgus durable flexible cable(10 million times)
Power Supply
220V 50/60Hz
Average Power
1500W
Machine Dimensions
1740*1360*1440mm
Weight
1100Kg



120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 0

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 1

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 2

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 3

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 4

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 5

120 Feeders Smd Led Making Machine HWGC PCB Production Line Equipment 6

 FAQ
Q: How is the training?
A: After buying our machines, your engineers can go to our company or it is so easy to operate. We have English user manual and guide video to teach you how to use the machine. The user manual will come with the machine together.

Q:Is it hard to use these machines?
A: No, not hard at all For our previous clients, at most 2 days is enough to learn to operate the machines.

Q:Does your machines have quality certificate?
A: All of our machines have passed CE certificate,ISO14001(BCC),ISO9001(IQNET) and have own paten.

Q:The Warranty of the machine?
A: One year, then the parts will be free for the buyer in the warranty. If there is any doubt in the process of operating the
machine, pls feel free contact us. We will help you in time.

Q:English version for these machines?
A: Yes, and we will reqularly update the software for customers.
