0201 , 0402 , 0603 , 0805 , 1206 , diode , triode, SOT and QFP , BGA with lead pitch ≥ 0.3mm (subject to dimension of 40*40mm and lead center distance 0.3mm) etc.
Pick And Place Machine , Chip Mounter Surface Mounter , Smt Machine
With the development of intelligent motion control system, visual recognition system, image processing system and other core technologies, our patch techn-ology is becoming more and more mature.
In terms of hardware manufacturing, the core parts are imported brands to ensure more stable, reliable and long-term product performance. After winning a variety of invention patents,utility model patents and software copyright,the current mounting standard has reached the international level.
We not only have a stable customer base in China, but also get more and more favor overseas.
porduct
The HW-DSQ800-120F is our most popular model with Vision. The HW-DSQ800-120F offers technologically advanced features with 260mm x 400mm work area, 120 single feeder positions where quick setup, easy of operation and high reliability are paramount.
System Features
* The highest quality with the most advanced equipment at a cost-effective solution
* Placement rates up to 25000-26000 cph
* Accurately places a wide range of components including 0201, 0402, LED, BGA, QFN...
| Placement rates | 26000CPH |
| Accuracy | ± .001” (0.02mm) |
| Voltage | 220AC |
| Weight | 1000kg |
| Warranty | 1 year |
| Suppport | Video Support |
| UI | The best GUI (graphical user interface) in its class using Windows®-based software allows programming in minutes |
| Max no. of Feeders (8mm tape) | 120 pcs |
| Max Board Size | 380mmX400mm |
| Smallest Component Capability | 0201 |
| Vision System | HWGC Vision |
| Vibratory Feeders | Loose, tube, stick (frequency & amplitude control) |
Our products are sold all over the world, you can rest assured.
