Vertical SMD Pick And Place Machine 4 Head Surface Circuit Board Assembly Machine

Vertical SMD Pick And Place Machine 4 Head Surface Circuit Board Assembly Machine

Products - SMD Pick and Place Machine
  • High Light

    Vertical SMD Pick And Place Machine

    ,

    4 Head SMD Pick And Place Machine

    ,

    OEM Circuit Board Assembly Machine

  • Placement Rates
    13000CPH
  • Voltage
    220AC
  • Weight
    800kg
  • Suppport
    Video Support
  • UI
    The Best GUI (graphical User Interface) In Its Class Using Windows®-based Software Allows Programming In Minutes
  • Max No. Of Feeders (8mm Tape)
    Up To 50 Tape Feeders
  • Vision System
    HWGC Vision
  • Vibratory Feeders
    Loose, Tube, Stick (frequency & Amplitude Control)
  • Place of Origin
    China
  • Brand Name
    HWGC
  • Certification
    CE
  • Model Number
    HW-T8-80F
  • Minimum Order Quantity
    1
  • Price
    usd+15000+pieces
  • Packaging Details
    Export wooden package
  • Delivery Time
    5-8work days
  • Payment Terms
    T/T
  • Supply Ability
    50+Pieces+Month

Vertical SMD Pick And Place Machine 4 Head Surface Circuit Board Assembly Machine

  • Vertical SMD Pick And Place Machine 4 Head Surface Circuit Board Assembly Machine
Get Price Contact Now



4 head Automatic Upright Surface Mounting Machine Cheap Vertical SMT Pick and Place Machine HW-T4SG-50F



The machine H4 with the ball screw and servo motor which is more stable and accurate than normal step motor, software designed and developed by our self. It is available in English. And we will keep updating it. Customers can get updated software regularly. Machine is of high quality,with at least one-year warranty, lifetime maintenance

Feature

1. SMT pick and place machine with 50 feeders +4 heads adopts Panasonic servo motor to ensure it is stable and accuracy 2. SMT pick and place machine uses imported Straight guide rail +screw Guide can get faster speed and more stable 3. Four mounting heads work together, under 6 cameras inspection,come with 50 feeder positions will make machine working more











Placement rates

13000CPH

Accuracy

± .001” (0.02mm)

Voltage

220AC

Weight

800kg

Warranty

1 year

Suppport

Video Support

UI

The best GUI (graphical user interface) in its class using Windows®-based software allows programming in minutes

Max no. of Feeders (8mm tape)

Max no. of Feeders (8mm tape)

Max Board Size

260mmX400mm

Smallest Component Capability

201

Vision System

HWGC Vision

Vibratory Feeders

Loose, tube, stick (frequency & amplitude control)





The HW vision System assist allows accurate placement of 0201, BGA, QFN, QFP,LED and a wide range of virtually all SMT components.



Vision System

The HW-series vision pick and place systems is easy to programming for all operators, Intelligent and fast to operation



Feeders

Yamaha Pneumatic feeder and Electricial feeder were adopted, sizes include 8mm, 12mm, 16mm, 24 mm, 32mm and 44mm.
