HWGC Pick And Place Vacuum Nozzle HW-T8-80F For SMD Machine

HWGC Pick And Place Vacuum Nozzle HW-T8-80F For SMD Machine

  • High Light

    HWGC Pick And Place Vacuum Nozzle

    ,

    220AC Pick And Place Vacuum Nozzle

  • Placement Rates
    13000CPH
  • Accuracy
    ± .001” (0.02mm)
  • Voltage
    220AC
  • Weight
    800kg
  • Warranty
    1 Year
  • Suppport
    Video Support
  • UI
    The Best GUI (graphical User Interface) In Its Class Using Windows®-based Software Allows Programming In Minutes
  • Max No. Of Feeders (8mm Tape)
    Up To 50 Tape Feeders
  • Max Board Size
    380mmX400mm
  • Smallest Component Capability
    0201
  • Vision System
    HWGC Vision
  • Vibratory Feeders
    Loose, Tube, Stick (frequency & Amplitude Control)
  • Place of Origin
    China
  • Brand Name
    HWGC
  • Certification
    CE
  • Model Number
    HW-T8-80F
  • Minimum Order Quantity
    1
  • Price
    usd+15000+pieces
  • Packaging Details
    Export wooden package
  • Delivery Time
    5-8work days
  • Payment Terms
    T/T
  • Supply Ability
    50+Pieces+Month

HWGC Pick And Place Vacuum Nozzle HW-T8-80F For SMD Machine

The HW-T8-80F is our most popular model with Vision. The HW-T4-44/50F offers technologically advanced features with 380mm x 400mm work  area



Pick And Place Machine , Chip Mounter Surface Mounter , Smt Machine

Introduction

The machine 50F with the ball screw and servo motor which is more stable and accurate than normal step motor, software designed and developed by our self.
It is available in English. And we will keep updating it. Customers can get updated software regularly Machine is of high quality with at least one-year warranty, lifetime maintenance.

Feature

1. SMT pick and place machine with 50 feeders +4 heads adopts Imported servo motor to ensure it is stable and accuracy 2. SMT pick and place machine uses imported Straight guide rail +screw Guide can get faster speed and more stable 3. Four mounting heads work together, under 6 cameras inspection come with 50 feeder positions will make machine working more

Part List

Pick and place machine:1Set 2.IC fixed support:4Sets (four M5*8, four M5*16) 3.JUKI nozzle:12Pcs (502*2,503*3,504*4,505*2,506*1) 4.Calibration suction nozzle:4PCS 5.Power wire:1PC 6.Fixed foot:4PCS (Diameter 20mm) 7.The keyboard and mouse:1Set 8.Nozzle calibration ink-pad:1Box 9.lubricant:1PC 10.Chassis key:1PC 11.PC:1Set 12.17-inch liquid crystal display:1Set

porduct description

The HW-T8-80F is our most popular model with Vision. The HW-T4-44/50F offers technologically advanced features with 380mm x 400mm work area, 80 single feeder positions (up to 120 feeders using bank feeders) where quick setup, easy of operation and high reliability are paramount.



System Features



* The highest quality with the most advanced equipment at a cost-effective solution

* Placement rates up to 13000 cph

* Accurately places a wide range of components including 0201, 0402, LED, BGA, QFN...




Placement rates 13000CPH
Accuracy ± .001” (0.02mm)
Voltage 220AC
Weight 800kg
Warranty 1 year
Suppport Video Support
UI The best GUI (graphical user interface) in its class using Windows®-based software allows programming in minutes
Max no. of Feeders (8mm tape) Max no. of Feeders (8mm tape)
Max Board Size 380mmX400mm
Smallest Component Capability 0201
Vision System HWGC Vision
Vibratory Feeders Loose, tube, stick (frequency & amplitude control)


The HW vision System assist allows accurate placement of 0201, BGA, QFN, QFP,LED and a wide range of virtually all SMT components.

Vision System

The HW-series vision pick and place systems is easy to programming for all operators, Intelligent and fast to operation



Feeders

Yamaha Pneumatic feeder and Electricial feeder were adopted, sizes include 8mm, 12mm, 16mm, 24 mm, 32mm and 44mm.
